This operation manual is a proprietary business secret that outlines the successful refurbishment process for repair of OBC EVC IDCM and data recovery. By following the provided instruction steps, which include text, images, and videos, you will be fully equipped to repair the OBC effectively and efficiently. Manual is non-refundable Each file edit costs 5 EVC- on first purchase you will receive 100
Info
You can charge this service: 1600€ You need 16 labor hours to deploy this repair if you are removing OBC OEM FIAT OBCM EVCC: OBC 4400€+tax Author: Vanja
Repair kit - Replacement parts (LIST AVAILABLE HERE)
VVDI - CG100X - Xprog Programmer
Online file editor (Here included)
HV Gloves
Soldering iron
Info
Repair operation steps
Step 1:
Before performing any work on the FIAT OBCM, it is mandatory to prepare a controlled and safe working environment in accordance with high-voltage safety protocols. Lvl 3 HV Access license needed.
Read error codes with diagnostic tool and confirm you have same error codes and faults.
Secure the work area – The workspace must be clean, dry, clearly marked as an HV zone, and equipped with proper safety gear (HV gloves, face shield, insulating mat).
Disconnect the 12V system
Perform safe high-voltage system shutdown – Using approved tools and following OEM procedures, disconnect the HV connectors and wait the required cool-down period for capacitor discharge.
Verify absence of voltage (Zero Voltage Verification) – Use an appropriate HV tester to ensure that no voltage is present in the system before proceeding.
Remove the battery pack – Once confirmed safe, proceed with mechanical removal of the battery pack using factory mounting points and proper lifting equipment
...
You have reached a restricted content! You must buy this online training operation manual to get access.
DQ381 DQ500 TCU Repair
375,00 € inc. VAT - 300,00 € exc. VAT
